| 总体尺寸overalldimensions |
整车操作质量operating weight |
8600KG |
轴距wheel base |
2280mm |
| 整机外形尺寸overalldimension(LXWXH) |
6050x2484x3453mm |
轮距wheel tread |
1785mm |
| 最小离地间隙Ground clearance |
300mm |
|
|
| 性能performance |
装载斗容 Load bucket capacity |
3 |
反铲斗容 Backhoe bucket capacity |
3 |
| 崛起力 Load breakout force |
47KN |
挖斗挖掘力 Backhoe digging force |
49.8KN |
| 装载举升能力 Load lifting capacity |
2500KG |
挖掘回转角 Backhoe swing angle |
180' |
| 铲斗卸载高度 Bucket unloading height |
2807mm |
挖斗卸载高度 Bucket unloading height |
4084/4720mm |
| 铲斗卸载距离 Bucket unloading distance |
801mm |
最大挖掘深度Max. Digging depth |
4303/5246mm |
| 铲挖深度 Digging depth |
30mm |
最大牵引力 Max. Traction force |
76KN |
| 发动机Engine |
型号 Mode |
904J-E36TA |
WP3.6NG1O1E680WP3.6NG112E680 |
Y C4A105Z-T20Y C4A11OZ-T23 |
WP4G95E221 |
| 制造商 Manufacturer |
铂金斯欧五perkins-Euro v |
潍柴欧五wei chai-Euro v |
玉柴国二yu chai-china ll |
潍柴国二 wei chai-china II |
| 吸气 inhale |
涡轮增压Turbo charge |
涡轮增压Turbo charge |
直列 -Inline direct直喷-injection水冷 -water cooled涡轮增压-Turbo charge |
直列 -Inline direct直喷-injection水冷 -water cooled涡轮增压 -Turbo charge |
| 排量Displacement |
3.6L |
3.6L |
4.8L |
4.5L |
| 气缸数 NO. of cylinders |
4 |
4 |
4 |
4 |
| 缸径cylinder diameter |
98 mm |
100 mm |
108 mm |
105 mm |
| 行程Trip |
120 mm |
114 mm |
132 mm |
130 mm |
| 发动机额定转速Rated engine speed |
2400rpm |
2200rpm |
2200rpm |
2200rpm |
| 额定功率 Rated power |
74.5 KW |
74 KW |
74 KW |
70KW |
| 最大扭矩Maximum torque |
430 N.m |
450 N.m |
400N. m |
38ON. m |
| 最大扭矩转速Maximum torque speed |
1500rpm |
1400-1600rpm |
1400-1700rpm |
1400-1600rpm |
| 转向系统steering system |
型式Type |
液压转向 hydraulic steering |
| 转向器型号steering gear model |
BZ Z-250 |
| 工作泵排量pump displacement |
63ml/r |
| 工作泵型号 pump model |
S GP2063 |
| 转向角steering angle |
士410 |
| 最小转弯半径 Min. Turning radius |
6581mm |
| 驱动桥Driving axle |
型号 Model |
26.22-1920/28.43M-1654 |
| 生产厂家 Manufacturer |
意大利卡拉罗 Italy carr aro |
| 额定前桥载荷 Rated front axle load |
22.5T |
| 额定后桥载荷 Rated rear axle load |
18.75T |
| 传动系统 Transmission |
变速箱Gearbox |
定轴式动力换挡 counter shaft powers hif |
| 型号 Model |
T LB1-4WD |
| 档位数Gears |
4F、4R前进4档, 后退4档 |
| 液力变矩器Hydraulic torque converter |
carr a ro |
| 冷却方式cooling mode |
油冷压力循环 oil-cooling pressure circulation |
| 轮胎tyre |
前 /后规格Front/Rear Mode |
14-17.5/19.5L-24 |
| 前轮气压 Front Tyre pressure |
0.4Mpa |
| 后轮气压 Rear Tyre pressure |
0.35Mpa |
| 最高车速 Max. Travel speed |
39km/h |
| 制动系统Brake system |
行车制动Traveling Brake |
湿式桥、 内置式、 自调节、 自平衡wet internal self-re gula tic self-balance type |
| 驻车制动 parking brake |
手动制动 Manual brake |
| 系统压力system pressure |
装载液压系统 Loading hydraulic system |
25Mpa |
| 挖掘液压系统Excavation hydraulic system |
25Mpa |
| 转向液压系统steering hydraulic system |
14Mpa |
